GSM Router (5G)SKU: 217251
![Allnet]()
EAN: N/A
ALLNET Wireless AX 5G/4G Router 3000Mbit, OpenVPN/Wireguard "OpenWRT" - 217251
Availability:
Nicht vorrätig
EAN: N/A
ALLNET Wireless AX 5G/4G Router 3000Mbit, OpenVPN/Wireguard «OpenWRT»
CHF 529.85 inkl.
Nicht vorrätig
WiFi-6 Dual-SIM 4G/5G Cellular Gateway/Router with embedded openWRT/openVPN/Wireguard
Reliable Cellular Networks in Rural Areas
GL-X3000 is a Wi-Fi 6 cellular gateway designed to provide reliable cellular networks in remote locations and high speed internet in urban areas. It has six external antennas for long range connection, two SIM Cards for selecting between the ISP with stronger connections, and Multi-WAN between the WAN port, SIM Card, and Repeater.
Supports 4G LTE & 5G NR
Dual-SIM Cards & Multi-WAN
Wi-Fi 6 Max. 574 Mbps (2.4GHz) + 2402 Mbps (5GHz) Wi-Fi Speeds
OpenVPN speed up to 150 Mbps WireGuard speed up to 300 Mbps
Dual-SIM Cards & Multi-WAN
Wi-Fi 6 Max. 574 Mbps (2.4GHz) + 2402 Mbps (5GHz) Wi-Fi Speeds
OpenVPN speed up to 150 Mbps WireGuard speed up to 300 Mbps
| Module: RM520N-GL | ||
|---|---|---|
| 5G NR | NSA | n1/ 2/ 3/ 5/ 7/ 8/ 12/ 13/ 14/ 18/ 20/ 25/ 26/ 28/ 29/ 30/ 38/ 40/ 41/ 48/ 66/ 70/ 71/ 75/ 76/ 77/ 78/ 79 |
| SA | n1/ 2/ 3/ 5/ 7/ 8/ 12/ 13/ 14/ 18/ 20/ 25/ 26/ 28/ 29/ 30/ 38/ 40/ 41/ 48/ 66/ 70/ 71/ 75/ 76/ 77/ 78/ 79 | |
| LTE | LTE-FDD | B1/ 2/ 3/ 4/ 5/ 7/ 8/ 12/ 13/ 14/ 17/ 18/ 19/ 20/ 25/ 26/ 28/ 29/ 30/ 32/ 66/ 71 |
| LTE-TDD | B34/ 38/ 39/ 40/ 41/ 42/ 43/ 48 | |
| LAA | B46 | |
| UMTS | WCDMA | B1/ 2/ 3/ 5/ 8/ 19 |
| GNSS | GPS/ GLONASS/ BDS/ Galileo/ QZSS | |
| Module: EM160R-GL | ||
|---|---|---|
| LTE | LTE-FDD | B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/B20/B25/B26/B28/B29?/B30/B32?/B66 |
| LTE-TDD | Intra-band and Inter-band | |
| DL 2CA | Intra-band and Inter-band | |
| DL 3CA | Intra-band and Inter-band | |
| DL 4CA | Intra-band and Inter-band | |
| DL 5CA | Intra-band and Inter-band within 5 bands | |
| DL 4×4 MIMO | B1/B2/B3/B4/B7/B25/B30/B32?/B38/B39/B40/B41/B66 | |
| DL 256QAM | Supported | |
| UL 2CA | Intra-band | |
| UL 64QAM | Supported | |
| UMTS | WCDMA | B1/B2/B3/B4/B5/B6/B8/B19 |
| GNSS | GPS/GLONASS/BeiDou(COMPASS)/Galileo | |
Notes: ?: For secondary component carrier only.
Technical Details:
| Interface | 1 x WAN Ethernet port 1 x LAN Ethernet port 1 x USB 2.0 port 1 x MicroSD card slot (Max.1TB) 2 x Nano SIM card slot 1 x Reset button |
| CPU | MediaTek Dual-core MT7981A, @1.3GHz |
| Memory / Storage | DDR4 512 MB / eMMC 8GB |
| Protocol | IEEE 802.11a/b/g/n/ac/ax |
| Wi-Fi Speed | 574Mbps (2.4GHz), 2402Mbps (5GHz) |
| Ethernet Speed | WAN Port: 10/100/1000/2500Mbps LAN Port: 10/100/1000Mbps |
| Antennas | 6 x Optional Antennas (4 for 4G LTE/5G NR, 2 for Wi-Fi) |
| LEDs | System / 5G WiFi / 2.4G WiFi / Internet / Cellular Signal Strength |
| Power Input | DC 9-36V |
| Power Consumption | <14W |
| Operating Temperature | 0 ~ 40°C (32 ~ 104°F) |
| Storage Temperature | -20 ~ 70°C (-4 ~ 158°F) |
| Dimension / Weight | 155 x 95 x 36mm / 520g |
