LoRa MCF88 LoRaWAN 4-20mA/0-10V to LoRaWAN® interface - 178313

LoRa MCF88 LoRaWAN 4-20mA/0-10V to LoRaWAN® interface

This interface has two 4-20mA and two 0-10V input channels. All these inputs are opto isolated and are useful to connect any kind of analog sensor and to forward measurements to the LoRaWAN® platform.

Technische Daten:

– CPU Cortex M4 – RTC – EEProm 32KB – Flash 1MB – Encryption AES 128 bit – LiPo rechargeable battery – Class C LoRaWAN® stack EU868, AS923 – 1000Vdc isolated analog inputs – 2 analog current inputs 4-20mA 12bits with disconnect alarm – 2 analog voltage inputs 0-10V 12bits – USB On The Go – IoT node setup ad firmware upgrade via USB interface – Power supply 10-36Vdc – Storage temperature range -20 + 80 °C – Working temperature range -10 + 70 °C
